EXACT12, 8XM12, 5-POLE, MOULDED CABLE 8000-88510-4520500 MURR ELEKTRONIKProduct Overview
The EXACT12-8xM12-5-Pole is a compact, pre-wired distribution module with eight M12 5-pole female connectors embedded in a moulded cable assembly. It is purpose-built for streamlined sensor/actuator cabling, reducing field wiring effort and improving reliability via industrial-grade connectors.
It follows the modular EXACT12 distribution platform from Murrelektronik, which is widely used for decentralized I/O systems.
Key Specifications & Features
| Feature | Specification / Notes |
|---|---|
| Connector Count | 8 × M12 female, 5-pole |
| Cable / Moulding | Whole module is delivered as a moulded cable assembly (i.e. permanently terminated) |
| Current Rating | Up to 4 A per contact (typical for 5-pole M12 in this system) Murrelektronik Shop+1 |
| Total Current / Feed Capacity | The feed / supply side must handle combined current; in similar modules total is often limited (e.g. 8 A) Murrelektronik Shop+1 |
| Voltage / System | 24 V DC supply typical for sensor / actuator systems |
| Protection / IP Rating | IP65 / IP67 protection when properly connected and mated Murrelektronik Shop+2Murrelektronik Shop+2 |
| Housing / Materials | Moulded in durable plastics / PUR / PVC blends suited to industrial environments |
| Cable Lengths & Variants | Various lengths offered (e.g. 3 m variants exist) Murrelektronik Shop |
| Temperature / Environmental | Suitable for typical industrial cabinet / field ambient ranges (e.g. –20 °C to +70 °C) |
| Certifications & Standards | Built to Murrelektronik’s EXACT12 system standards; compatible with existing EXACT12 modules and interfaces |
Engineering Insights & Use Cases
-
Plug-and-play Distribution
This moulded cable module eliminates the need to wire individual connectors separately, saving installation time and reducing wiring errors. -
Modular System Compatibility
Because it aligns with the Murrelektronik EXACT12 distribution system, it interfits seamlessly with other modules in that ecosystem (e.g. feed modules, extension modules, etc.). -
Current Budgeting
While each output supports up to ~4 A, the supply feed must be rated to support the sum of currents. Careful planning ensures no single channel or overall feed exceeds limits. -
Environmental Reliability
With IP65/67 ratings when mated, the unit is suited for typical industrial and factory floor conditions, but not necessarily for direct immersion unless designed for that. -
Reduced Connector Stress
The moulded nature means fewer mechanical joints and potential failure points; less chance of loose connectors or wiring faults over time.
Suggested Product Page Description
EXACT12-8xM12-5-Pole Moulded Cable Module
A robust, factory-terminated distribution module featuring 8 M12 female 5-pole connectors in a sealed moulded cable assembly. Designed for 24 V DC sensor and actuator networks, this module supports up to 4 A per connector and provides industrial IP65/67 rated protection. Simplify your wiring, reduce connector points, and ensure reliable signal distribution across your control system. Compatible with Murrelektronik’s EXACT12 modular infrastructure.
Key Highlights:
-
8 × M12 5-pole female connectors
-
Up to 4 A current per contact
-
Factory-moulded cable assembly reduces wiring effort
-
IP65/67 rated for rugged environments
-
Seamless integration with EXACT12 system modules
