Automatic carton sealer with manual box dimensioning and flap closing
system equipped with two side belts. It folds the four upper flaps and seals
automatically the top and bottom of uniform size American-type boxes.
The regulations are fast and easy. Equipped with detectors for the end or
breakage of adhesive tape managed by PLC. To be used on fully automatic
lines without operators. Configuration of the box parameters both on the
right and left side of the machine. Machine includes infeed and outfeed
rollers and wheels, representing a practical and simple packaging station
Technical details
+ Weight: 280 kg
+ Power supply: 380 Volts – 50 / 60 Hz
+ Box transfer speed: 19 mt / min
+ Maximum box weight: 30 kg
+ Machine dimensions: L 2536 x W 1021 x H 1953 -2153 mm
+ Emergency stop in compliance with CE regulations
+ Adhesive tape: Kraft, Polypropylene, PVC
+ Standard taping head: 50 – 75 mm
+ Working table height: 660 – 860 mm
+ Tape end detector managed by PLC
+ Tape break detector managed by PLC
+ Left and right box adjustment system
+ Warning light
