24V DC 8 CHANNEL SINK INPUT MODULE.

Description: The Allen-Bradley 1734-IB8 is a POINT IO module that features Eight (8) Discrete sinking input channels. It has One (1) group of channels with Eight (8) inputs per channel. It accepts nominal signal voltage of 24VDC and compatible with any POINT IO communication adapter for implementing distributed I/O architecture. This module requires 1734-TB or 1734-TBS wiring base assembly.

Weight, approx. :31.8 g (1.12 oz)
Dimensions: 56 x 12 x 75.5 mm (2.2 x 0.47 x 2.97 in.)
Brand: Allen-Bradley
Part Number/Catalog No.: 1734-IB8
Series: POINT I/O
Module Type: Digital DC Sinking Input
Input Voltage: 24 Volts DC
POINTBus Current: 75 mA
UPC: 10612598308573
